The Galaxy type "FC" wellhead line has been designed for shallow, low-pressure service wells. The type "FC" casing head incorporates a full opening tapered bore design. Outlets on the type "FC" casing head are 2" line pipe threaded.
"FC" casing head housings are designed to receive "FC" manual slips, and an O-ring type “FC” primary seal assembly. Type "FC" casing heads are engineered for use with Galaxy type "GA" API 6A 7 1/16” lower flanged tubing heads that incorporate an integral secondary seal. The "FC" series is ideal where cost efficiency is of prime importance.
Item |
Size |
Lower Connection |
Suspended Casing Size |
Part Number |
Casing Head |
7 1/16" API 2000 |
7" SOW |
N/A |
30-0200 |
Casing Head |
7 1/16" API 2000 |
7" 8-RD |
N/A |
30-0204 |
Manual Hanger |
7" Nominal |
N/A |
4 1/2" |
30-0300 |
Primary Seal |
7" Nominal |
N/A |
4 1/2" |
30-0350 |
|
